Are you still managing a separate concrete mixer and a standalone pump on your job site? YG Machinery solves this problem with its high-performance Concrete Mixer And Pumping Machine. This all-in-one unit mixes cement, sand, aggregate, and water on-site, then pumps the finished concrete directly to where you need it. No extra vehicles, no extra crew, and no wasted time transferring materials between machines.
The YG concrete mixer with pump machine delivers output volumes of 20–40 M³/h and handles aggregate sizes up to 40 mm. It suits a wide range of concrete mixes and project scales. YG Machinery currently offers two main models — the YG-350 and the YG-550 — both built to meet international export standards. Customers across Asia, Africa, the Middle East, and Southeast Asia trust YG equipment on their construction sites.
Parameters of YG Concrete Mixer And Pumping Machine
If you are comparing a concrete mixer pump for sale, these specifications will help you choose the right model. The YG-350 suits small-to-medium projects, while the YG-550 handles higher-volume demands.
| Model | YG-350 | YG-550 |
| Theoretical delivery volume | 20-30M3/h | 40M3/h |
| Bone particle diameter | 0.5-40mm | 20-40mm |
| Greatest pressure | 20mpa | 20mpa |
| Bore*Stroke | 180*1000mm | 200*1110mm |
| Motor Power | 45kw | 55kw |
| Oil pump power | 100(column)L/S | 140(column)L/S |
| Delivery pipe | 125mm | 125mm |
| Genset power | 150kw | 150kw |
| Machine size | 6100*2000*2700mm | 6200*2000*2700mm |
| Weight | 5500kg | 6500kg |
The YG-350 works well for residential construction, floor screed jobs, and rural road projects. The YG-550, in contrast, offers a higher output of 40 M³/h, making it a strong choice for commercial building sites and larger infrastructure works. Not sure which model fits your project? Contact our engineers directly for a free recommendation.
What Is a Concrete Mixer And Pumping Machine？
A concrete mixer and pumping machine is a self-contained construction unit. It mixes cement, sand, aggregate, and water, then pumps the finished concrete through pipelines to the target location. In other words, it replaces two separate machines: a stand-alone mixer and a standalone pump. As a result, it saves labor, cuts equipment costs, and speeds up the construction process considerably.
YG’s small concrete mixer pump uses an S-valve distribution system to guide concrete flow smoothly between two pumping cylinders. The machine features a PLC intelligent control panel and a wireless remote controller with a working range of up to 1,000 meters. Additionally, a centralized auto-lubrication system keeps moving parts running longer without frequent manual maintenance. Both electric and diesel-powered versions are available, so you can match the machine to your site conditions.
Application Areas of Concrete Mixer With Pump Machine
This equipment fits a wide range of construction scenarios. Below are the most common applications.
1. Residential and Commercial Building Construction
This machine handles floor slab pours, column casting, beam placement, and rooftop concrete work. It delivers concrete smoothly to upper floors without the need for a crane or bucket system. Contractors use it on small residential projects and mid-rise commercial buildings alike.
2. Road and Bridge Engineering
Highway pavement, bridge decks, and viaduct structures all require large volumes of concrete delivered under pressure. The high pumping pressure of up to 20 MPa ensures concrete reaches difficult spots along the structure reliably and efficiently.
3. Tunnel and Underground Works
Subway construction, mine shaft backfilling, and tunnel lining demand reliable concrete delivery in tight spaces. The compact dimensions of YG machines make them practical for underground environments where larger truck-mounted pumps cannot operate.
4. Rural Infrastructure and Small Township Projects
Large pump trucks often cannot access narrow village roads or small construction sites. YG’s machine fills this gap. It is mobile, easy to transport on a flatbed truck, and requires only a small crew. Consequently, it has become a popular choice for rural road construction and new village building projects across developing regions.
5. Water Conservancy and Floor Heating Works
Reservoirs, hydropower stations, and port wharves often require pressure grouting in challenging conditions. Furthermore, fine aggregate concrete filling for underfloor heating systems demands precise, controlled delivery. The YG-350, with its ability to handle aggregate as small as 0.5 mm, handles both applications well.
How Does a Concrete Mixer And Pumping Machine Work？
Understanding the working process helps you get the best results from this equipment. Here is a clear overview:
- Feeding: The operator loads cement, sand, aggregate, and water into the wide-angle hopper. The hopper design maximizes suction efficiency and reduces material spillage during loading.
- Mixing: The mixing drum blends all materials into uniform concrete. This stage runs four to six times faster than a traditional fixed mixer, which significantly shortens cycle time on busy job sites.
- S-Valve Switching and Pumping: As the drum feeds concrete into the pumping chamber, the S-shaped distribution valve smoothly directs the flow between two pumping cylinders. The dual-cylinder piston mechanism then builds up to 20 MPa of working pressure, pushing concrete steadily through the 125 mm delivery pipe.
- Delivery and Remote Control: Mixed concrete travels through steel pipes and flexible hoses directly to the formwork. Throughout the process, the operator monitors and adjusts the machine via the PLC control panel or wireless remote. This setup allows one person to manage both the pump and the pour simultaneously.
Why Choose YG Concrete Mixer And Pumping Machine？
1. True All-in-One Design
YG’s machine combines mixing, feeding, and pumping in a single unit. This replaces a separate mixer, a transport vehicle, and a standalone pump. As a result, you save on equipment costs, reduce your site footprint, and need fewer workers to complete the job.
2. Premium International Components
Key hydraulic parts come from internationally recognized suppliers in Japan and the USA. Electrical control systems use trusted components from Germany. These choices ensure reliability under heavy-duty conditions and keep long-term maintenance costs low.
3. Carbide Alloy S-Valve for Long Service Life
The spectacle plate and cutting ring inside the S-valve use high-hardness tungsten carbide alloy. This material lasts approximately three times longer than traditional cast iron alternatives. Longer wear life means less downtime and lower operating costs over the machine’s lifetime.
4. Wireless Remote Control up to 1,000 Meters
Operators can control the machine from up to 1,000 meters away. This improves job site safety and allows one operator to move freely between the pump and the pour point. In addition, it eliminates the need for a dedicated person to stand at the machine during operation.
5. Dual High/Low Pressure Switching
YG machines include a high/low pressure switching valve. In high-pressure mode, the machine delivers concrete over long distances at a controlled flow rate. In low-pressure mode, it increases volume for close-range, high-speed pours. This flexibility lets you adapt the machine to different site conditions without changing equipment.
6. Automatic Centralized Lubrication
A fully automatic lubrication system distributes oil to all moving parts at set intervals. This reduces manual maintenance and extends the life of seals, cylinders, and joints. For contractors running long shifts, this feature helps prevent costly unplanned repairs and keeps the machine running smoothly.
FAQ About Small Concrete Mixer Pump
A concrete mixer pump is a compact, self-contained unit that mixes and pumps concrete on-site. It suits small-to-medium projects with limited site access. A truck-mounted pump, in contrast, is much larger and requires pre-mixed ready-mix concrete. It suits large-scale high-rise projects where high output volume is the priority.
The YG-350 delivers concrete up to 150 meters horizontally and up to 50 meters vertically. Actual range depends on pipe diameter, aggregate size, and concrete consistency. Using the standard 125 mm delivery pipe with a well-mixed batch generally gives the best delivery results.
The YG-350 handles aggregate from 0.5 mm to 40 mm in diameter, covering both fine screed mixes and coarser concrete. The YG-550 handles aggregate in the 20–40 mm range. For fine aggregate projects such as floor heating screed, the YG-350 is the recommended choice.
Yes. The machine is compact enough to transport on a standard flatbed truck, and the diesel-powered version operates without a fixed power supply. This makes it practical for rural roads, village building projects, and township infrastructure where large truck-mounted pumps cannot reach.
YG Machinery provides full technical manuals, video operation guides, and remote troubleshooting support. Spare parts are available globally. Our engineering team supports customers by WhatsApp, email, and phone, and offers guidance on model selection and pipeline setup before purchase.
YG Concrete Mixer And Pumping Machine for Sale
YG Machinery currently offers the YG-350 and YG-550 for sale. Both models are available in electric and diesel versions and meet international export standards. Beyond the concrete mixer pump for sale, YG Machinery also offers complementary equipment to support your full project:
Mortar Spraying Machine: Automates wall plastering and mortar application for faster, more uniform coating on interior and exterior surfaces.
Automatic Wall Rendering Machine: Handles mechanical wall smoothing and finishing, reducing wall labor costs significantly on large building projects.
Laser Screed Machine: Uses laser guidance to level concrete floors to precise flatness tolerances, suited for warehouses, parking lots, and commercial flooring projects.
Contact YG Machinery today to get a free quote or speak with an engineer about which model best fits your project. Our team typically responds within 24 hours.
