When you compare Bopp Tape Slitting Machine Price, you want a machine that delivers true speed, precision, and low long‑term cost. YG Machinery builds heavy‑duty slitting and rewinding systems for BOPP tape, flexible films, and paper. Our equipment serves as a dependable high‑speed slitting machine and a versatile slitters and rewinder for many converting tasks. With smart controls and a rigid frame, YG machines help you boost output while cutting waste. We focus on straightforward, operator‑friendly design. So your team learns fast and runs safely. Moreover, our factory‑direct approach gives you honest value. You receive a fair Bopp Tape Slitting Machine Price without dealer markups. In the following sections, you will see key parameters, efficiency tips, AI upgrades, and clear buying guidance.
Bopp Tape Slitting Machine Parameters and Key Specs
The technical data below directly shape the cost of your BOPP slitting line because wider working widths and higher installed power increase capability and long‑term efficiency. The table covers our three main models. All units run at speeds up to 350 meters per minute, handle unwind diameters up to 1400 mm, and rewind diameters up to 1000 mm. The minimum slitting width is 30 mm. Power supply is 380 V, 50 Hz. Note that duplex turret operation doubles rewind stations and enables non‑stop production. These robust slitting systems fit continuous converting lines
| Model | YG- 1300 | YG- 1600 | YG- 1800 |
| Max width | 1300mm | 1600mm | 1800mm |
| Max Diameter for unwinding | ￠1400mm | ￠1400mm | ￠1400mm |
| Minimum width of slitting | 30mm | 30mm | 30mm |
| Max Diameter of rewinding | ￠1000mm | ￠1000mm | ￠1000mm |
| Speed | ≤350m/min | ≤350m/min | ≤350m/min |
| Total Power | 24kw | 26kw | 30kw |
| Power supply | 380V/50hz | 380V/50hz | 380V/50hz |
| Weight | 4000kg | 4500kg | 5500kg |
| Overall dimension(LxWxH) | 3300x3150x1930(mm) | 3300x3450x1930(mm) | 3300x3650x1930(mm) |
How to Boost BOPP Slitting Efficiency with a High-Speed Slitting Machine?
Food packaging plants face tight deadlines and strict hygiene rules. A high‑speed slitting machine helps you satisfy both demands. First, servo‑driven winding keeps web tension steady from core to full roll. This stops film stretching and edge curl. As a result, roll quality stays high. Second, automatic knife positioning cuts setup time sharply. Operators can switch slitting widths in just a few minutes. Furthermore, non‑stop operation is vital for lean production. A high‑speed slitting machine fitted with a duplex turret unloads finished rolls without pausing. So you gain extra output every shift. In addition, clean shear‑cut blades generate very little dust. This matters for food‑grade BOPP film. Therefore, you protect product safety and your brand. YG machines use digital tension readouts and quick‑lock core chucks. These features reduce manual tweaks. Overall, pairing smart automation with basic operator training lifts daily efficiency. Many customers see a 20–30 percent output gain after upgrading to our high‑speed slitting machine.
AI Upgrades for Paper Roll Slitting & Rewinding Machine Performance
AI technology is transforming standard converting lines. Our paper roll slitting & rewinding machine integrates intelligent modules that raise quality and reduce waste. Below are the main AI‑driven functions.
- AI Vision Inspection: High‑resolution cameras scan the film surface in real time. They spot gels, fisheyes, and tiny scratches instantly. The system then marks defects or stops the line. This slashes customer returns.
- Auto Web Guiding: A camera tracks the exact web edge. It sends correction pulses to the unwind stand. So the film stays perfectly on track. This feature is essential for a paper roll slitting & rewinding machine handling thin or delicate substrates.
- Automatic Tension Regulation: AI learns the changing inertia of unwind and rewind rolls. It adjusts motor torque moment by moment. Therefore, you avoid loose cores, telescoping rolls, or baggy edges. Slit widths remain accurate.
- Online Defect Detection: The software logs each flaw with its position data. Operators review reports after the run. You can pull out bad rolls before shipping. This builds strong trust with your buyers.
- Predictive Maintenance: Vibration and temperature sensors monitor main bearings and blades. The system gives an early warning before a part wears out. In turn, you prevent surprise downtime. This protects your investment and keeps your slitter investment truly worthwhile over years of service.
All AI functions come pre‑integrated into the YG control system. You need no third‑party add‑ons. Moreover, the same smart modules work when you run the line as a paper roll slitting & rewinding machine for label face stock or kraft paper. In short, AI raises consistency and greatly lowers human error.
Why More Manufacturers Choose Duplex Slitters And Rewinder?
The shift to duplex turret winding is clear across the converting industry. More plants want uninterrupted production. Here are the main reasons.
- Non‑stop Turret Unloading: Duplex turret systems feature two rewind shafts on a rotating turret. One shaft builds finished rolls while the other starts fresh cores. The machine switches over automatically at full speed. You never pause for roll changes. This lifts daily output dramatically.
- Higher Throughput and Less Labor: A single operator can run the entire line. The machine handles cut, transfer, and new core placement cycles alone. So you lower labor cost and raise capacity. YG’s duplex models reach 350 meters per minute. Actual production stays high because there is no stop‑start waste.
- Better Rewind Quality: Two independent shafts mean consistent nip pressure on both stations. You get firm, even rolls with clean edges every time. This is critical for adhesive tape converting. Slitting precision also improves because line speed never fluctuates during changeover.
- Versatility: Our duplex design also processes paper rolls, laminated films, and label stock. Thus, the machine acts as a high‑speed slitting machine and a flexible converting solution for multiple product families.
In short, duplex turret models carry a slightly higher initial investment. However, they pay back quickly through extra productivity. When you calculate added output per year, the upgrade is a smart financial move.
How to Select a BOPP Film Slitting Machine?
Follow these steps to find the right configuration for your plant.
- Define your material and maximum width. Measure your widest film roll. Choose a model that covers your range. YG offers 1300 mm, 1600 mm, and 1800 mm working widths. Also confirm thickness. Our machines handle standard BOPP grades with ease.
- Decide your required automation level. Some converters need basic manual slitting. Others want automatic knife setting and laser core alignment. More automation raises the initial Bopp Tape Slitting Machine Price but saves labor and setup time. Pick based on your order mix and changeover frequency.
- Evaluate speed against actual production. A high‑speed slitting machine rated at 350 m/min may run steadily at 250–300 m/min under real conditions. Ask about ramp‑up and deceleration times. YG shares real performance data, not just peak numbers.
- Check AI options. If zero‑defect rolls matter, ask for AI vision and auto tension modules. These features improve quality for sensitive food packaging and high‑value tapes.
- Confirm after‑sales support. YG Machinery provides online technical help, spare parts catalogs, and remote installation guidance. Our engineers can also travel to your site when needed.
- Request a detailed quotation. Compare total cost of ownership, not just the headline price. Look at power use, blade life, and maintenance access. YG gives a transparent breakdown.
Following this checklist will help you choose a slitter that fits your budget and production goals. Reach out to our team for a personalized recommendation.
Bopp Tape Slitting Machine Price – YG Factory Direct Advantages
Why does YG offer such a competitive Bopp Tape Slitting Machine Price? We sell straight from our manufacturing base. There are no dealer layers. You pay for engineering, quality components, and assembly, not for sales commissions. Our machines use widely available industrial parts. This keeps spare costs low forever. You also receive lifetime technical guidance.
We configure each order to your precise needs. Choose between standard or duplex turret. Add AI modules as your market demands. Our engineers help you design the best solution. Then we provide a clear quotation in under 24 hours. In addition, you get a solid warranty on main mechanical and electrical parts. This gives you real peace of mind.
Beyond BOPP slitting, YG Machinery supplies a wide range of industrial equipment. We also manufacture egg tray making machines, food carts, generator sets, EV charging piles, tire recycling lines, sandblasting rooms, and more. So we can support your full production line with one reliable partner. Our cross‑sector experience proves our engineering depth.
Ready to move forward? Send us your material type, maximum width, and daily output target. We will propose the ideal slitters and rewinder setup. Then we will send you an accurate Bopp Tape Slitting Machine Price with shipping details. Click the inquiry button or email us today. Let YG Machinery help you grow your converting business.
