Concrete Shot Blaster For Sale is a professional floor preparation solution designed for concrete and steel surface treatment. It uses high-speed steel shot impact to clean, roughen, and prepare surfaces for coating, waterproofing, and resurfacing work.
This equipment plays an important role in modern construction projects. It improves bonding strength between the base surface and coating layers. At the same time, it removes weak layers such as laitance, dust, old markings, and contaminants.
In practical applications, contractors use this Floor Blasting Machine in bridge decks, airport runways, industrial workshops, and municipal roads. It supports stable and repeatable results, which helps maintain consistent project quality.
Key working advantages include:
- High cleaning efficiency for large surfaces
- Dust-free operation with closed recycling system
- Stable surface roughness for coating preparation
- Reduced manual labor demand on-site
Because of these advantages, Concrete Shot Blaster For Sale becomes an efficient choice for modern road and floor construction projects.
Product Parameter for Concrete Floor Shot Blaster
The following table shows detailed technical specifications of YG shot blasting equipment. These parameters help users select the right model for different construction conditions.
| Model | YG-270(Single) | YG550/600(Double) | YG-850(Double) | |
| Shot Blasting Wheel Diameter | 200mm | |||
| Working width | 270 mm | 550/600 mm | 800 mm | |
| Walking speed | 0.5~20 m/min | 0.5~33 m/min | ||
| Concrete surface cleaning efficiency | ≥180 m2/h | ≥400 m2/h | ≥600 m2/h | |
| Steel plate surface cleaning efficiency | 15-25 m2/h | 75-100 m2/h | 100-160 m2/h | |
| Dust connection pipe diameter | 120 mm | 150 mm | ||
| Suggest the diameter of steel balls | 1.2-1.5 mm | 1.5-1.8 mm | ||
| Steel pill consumption | 10 g/m2 | |||
| Supporting dust collector | Seven-core automatic backflush vacuum cleaner | Eight-core automatic backflush vacuum cleaner | ||
| Shot wheel motor | Power consumption | 11 kW | 11*2 kW | 15*2 kW |
| Input Current | ≤ 15 A | ≤ 22*2 A | ≤ 28*2 A | |
| Walking motor | Power consumption | 0.5 kW | 1.5 kW | |
| Input Current | 1 A | 3 A | ||
| Size (mm) | 1000*300*1100 | 1950*720/775*1400 | 1950*1020*1550 | |
| Weight | 150 kg | 570 kg | 700kg | |
| Power connection requirements | 400V, 50Hz, 100A, CEE socket | |||
This equipment supports different project scales. It allows flexible selection based on efficiency needs and surface conditions.
Shot Blasting vs Sand Blasting for Floor Blasting Machine
Shot blasting and sand blasting both prepare surfaces, but their working methods differ significantly.Shot blasting uses mechanical acceleration to throw steel shots onto the surface. It cleans and textures the surface in one step. It also collects and recycles abrasives automatically.
Sand blasting uses compressed air to spray abrasive materials. It depends more on manual control and external cleanup.
Key comparison points:
- Efficiency difference:Shot blasting can reach up to 600 m²/h on concrete surfaces. Sand blasting works slower in large areas.
- Environmental performance:Shot blasting uses a closed dust collection system. It reduces airborne dust during operation.
- Operation cost:Shot blasting recycles steel shot automatically. Sand blasting requires frequent abrasive replacement.
- Application stability:This system provides more consistent surface results.
Therefore, Concrete Shot Blaster For Sale is more suitable for large-scale industrial and municipal projects.
Steel Shot Size Impact on Floor Shot Blasting Machine
Steel shot size directly affects surface texture and cleaning performance. Most systems use 1.2–1.8 mm steel shot.
Main effects of steel shot size:
- Smaller shot (1.2–1.4 mm)
Creates finer surface texture and smoother finish. It is suitable for coating preparation work. - Medium shot (1.5 mm)
Balances cleaning force and surface smoothness. It is widely used in general projects. - Larger shot (1.6–1.8 mm)
Provides stronger impact force. It improves cleaning speed for heavy contamination surfaces.
Steel shot consumption usually ranges from 10–50 g/m² depending on surface condition. Proper selection helps maintain stable performance and reduces waste.
How Concrete Shot Blaster For Sale Reduces Labor Cost?
Concrete Shot Blaster For Sale helps contractors reduce labor cost through mechanized operation.
- One operator control system
A single operator can manage the machine easily. This reduces the need for multiple manual workers. - Faster working speed
High-speed blasting increases daily output. It allows more area to be completed in less time. - Reduced cleaning workload
The dust collection system captures dust and debris during operation. This reduces post-work cleaning. - Lower rework rate
Uniform surface roughness improves coating adhesion. It reduces repair and rework requirements. - Continuous operation capability
The machine supports long working cycles. It reduces downtime and improves labor efficiency.
Project Duration Reduction Analysis for Floor Shot Blasting Machine
Floor Shot Blasting Machine significantly improves project speed in surface preparation work.
Traditional surface preparation methods often require several days for large areas. Manual grinding also limits consistency and speed.
In contrast, shot blasting equipment offers higher efficiency:
- Concrete surface efficiency reaches up to 600 m²/h
- Steel surface efficiency reaches up to 160 m²/h
- Continuous working mode supports long-hour operation
Project time comparison example:
- Traditional method: 5–7 days for medium project
- Shot blasting method: 1–2 days for same area
This time reduction helps contractors complete coating, waterproofing, or paving stages earlier. It improves overall project scheduling and coordination.
YG Shot Blasting Machine for Sale Floor Blasting Machine Solutions
YG Machinery provides a complete range of road and floor preparation equipment. The Concrete Shot Blaster For Sale series includes YG-270, YG550/600, and YG-850 models.
Each model supports different working widths and project sizes. Users can select suitable equipment based on job requirements.
Besides Floor Blasting Machine solutions, YG also provides:
- Road roller machines for compaction work
- Crack sealing machines for road maintenance
- Laser screed machines for concrete leveling
- Road marking machines for traffic projects
These machines support full construction workflow from preparation to finishing.
YG equipment focuses on stable performance and practical design. It helps contractors improve productivity and reduce operating cost in real construction environments.
