The YG-240 series represents a significant advancement in compact and efficient water well drilling technology. This small water well drilling rig is engineered for property owners, farmers, and contractors needing a reliable, easy-to-transport solution for creating water sources. Available in two robust models, the YG-240-22P and YG-240-30P, this rig balances power with portability. Its intelligent design focuses on simplifying the drilling process in remote or confined locations where larger equipment cannot operate, making it an ideal small water well drilling machine for a variety of essential projects.
Technical Specifications of Our Small Water Well Drilling Rig
| Model | YG-240-22P | YG-240-30P |
| Dimension | 1450*1550*1970mm | 2000*1230*2090mm |
| Weight | 200kg | 200kg |
| Drill rod diameter | 42mm | 51mm |
| Drill rod length | 1.5m/unit | 1.5m/unit |
| Rod change method | Full automatic screw thread | Full automatic screw thread |
| Max drilling depth | 200m | 200m |
| Diesel engine power | 22HP | 30HP |
| Drilling hole diameter | Within 280mm | 100mm-240mm |
| Lifting height | 2.5m | Max 2.5m |
| Lifting force | 1000kg | 2000kg |
Key Applications for a Small Well Drilling Rig
- Residential Water Independence: Perfect for homeowners seeking to drill a private well for household use, providing a self-sufficient and often cost-effective water supply.
- Agricultural and Irrigation Support: Farmers can use this rig to create water sources for crop irrigation, livestock watering, or greenhouse operations, enhancing farm resilience.
- Remote Site and Camp Supply: Essential for establishing water access in cabins, remote work camps, or off-grid living situations where municipal water is unavailable.
- Construction and Exploration: Useful for creating temporary water supply on construction sites or for preliminary geological survey sampling.
Core Components of a Portable Well Drilling Machine
- Powerful Diesel Engine: The heart of the machine, offering 22HP or 30HP of reliable power, ensuring consistent performance without dependency on electrical grids.
- Automatic Rod System: The full-automatic screw thread mechanism allows for quick and safe addition or removal of drill rods, significantly boosting operational efficiency and safety.
- High-Capacity Lifting Gear: With a lifting height of 2.5 meters and a force of 1000-2000KG, the system handles drill rods and casings with ease in various soil conditions.
- Compact Mobile Chassis: The entire unit is designed for easy transport on a small trailer, making it a truly portable well drilling machine that can be moved by vehicle to the job site.
YG-240 Series: Key Features and Advantages
1. Robust Power for Demanding Tasks: Equipped with a trustworthy diesel engine, this rig delivers ample torque to handle a range of soil conditions, from clay to moderately rocky layers, ensuring drilling progress is maintained.
2. Unmatched Operational Efficiency: The patented full-automatic screw thread rod change system is a game-changer. It minimizes manual labor, reduces setup time between rods, and allows operators to focus on the drilling process itself.
3. Superior Portability and Access: Weighing only 200-300 kg with a compact footprint, this is one of the most mobile rigs in its class. It can be easily towed by a standard vehicle and positioned in tight spaces where larger rigs cannot reach.
4. Adaptable Drilling Performance: With a maximum depth of 200 meters and a hole diameter range of 100-280mm, this machine is adaptable for most common residential, agricultural, and small commercial water well projects.
5. Built for Durability and Simplicity: YG machinery constructs its rigs with heavy-duty materials for longevity. The controls are intuitively designed, making the learning curve shorter for new operators, which reduces downtime and operational costs.
6. Comprehensive Support from YG: Choosing YG means access to more than just a machine. It includes clear documentation, accessible spare parts, and reliable technical support to keep your operations running smoothly.
Frequently Asked Questions About Small Water Well Drilling Machines
A1: Both models can drill to a maximum depth of 200 meters. This depth is suitable for accessing aquifers for most residential, agricultural, and small-scale commercial water supply needs.
A2: It is highly portable. The rig is designed with an integrated trailer base and a low total weight, allowing it to be easily transported by a light truck or SUV to remote or difficult-to-access job sites.
A3: Yes, the combination of a powerful diesel engine and sturdy components allows it to tackle various ground conditions. While it is highly effective in clay, sand, and soft rock, extremely hard or consolidated rock formations may require specialized drill bits or additional equipment, which YG can advise on.
A4: The rig is designed for relative ease of use. YG provides a detailed operation manual and basic guidance. Individuals with general mechanical aptitude can learn to operate it effectively. For optimal results and safety, familiarization with local drilling practices and geology is recommended.
A5: Our commitment includes a standard warranty on the machine, lifetime access to technical consultation for troubleshooting, and support in sourcing genuine replacement parts. This comprehensive support ensures the long-term performance and reliability of your small water well drilling machine.
Your Trusted Partner in Drilling Solutions
YG machinery combines industry expertise with practical engineering to deliver durable and effective drilling equipment. Our focus is on providing not just a machine, but a reliable solution backed by clear communication, dependable logistics for global delivery, and ongoing support. We understand that your project’s success depends on the performance of your equipment, and we are committed to being a partner you can trust from inquiry through to long-term operation.
Get Your Personalized Quote Today
If you are looking for a dependable, efficient, and portable drilling solution, the YG-240 series is designed to meet your needs. We encourage you to reach out to our technical sales team with your specific project details, such as desired well depth, soil conditions, and location. Contact YG now to discuss your requirements, request a detailed specification sheet, and receive a competitive quote. Let us help you secure your water supply.
