If you look for a reliable egg tray making machine for sale, YG is your ideal choice. YG focuses on pulp molding machinery production for years. We design and manufacture practical equipment for global buyers. This machine takes waste paper as raw material. It turns waste paper into durable paper trays easily. Besides standard egg trays, it supports multiple pulp product production. It fits small workshops, poultry farms and large packaging factories perfectly. YG offers flexible models to match different output needs. All equipment runs steadily with low operation cost.
Paper Egg Tray Making Machine Technical Parameters
Below are core specifications of YG mainstream models for your reference.
| Model | YG-1*3 | YG-1*4 | YG-3*4 | YG-4*4 | YG-4*8 | YG-5*8 | YG-6*8 |
| Capacity (pcs/h) | 1000 | 1500 | 2500 | 3500 | 4500 | 5500 | 7000 |
| Forming Mould Quantity | 3 | 4 | 12 | 16 | 32 | 40 | 48 |
| Total Power (kW) | 40 | 40 | 50 | 60 | 130 | 140 | 186 |
| Electricity Consumption (kw/h) | 28 | 29 | 35 | 42 | 91 | 98 | 130 |
| Worker | 3-5 | 4-6 | 4-6 | 4-6 | 4-6 | 5-7 | 6-8 |
Moreover, YG supports custom voltage and size. Drying systems also have multiple options for selection. You can pick natural drying or automatic drying lines as you like.
Working Principle Of Egg Tray Maker Machine
The egg tray maker machine adopts simple pulp molding technology. First, waste paper mixes with water in the pulper. The machine stirs the mixture into even pulp. Then pulp flows to the forming area. Vacuum pressure adsorbs pulp on custom molds. Extra water filters out quickly. After molding, trays separate from molds. Finally, wet trays go into drying systems. The whole process runs smoothly in a loop. No complex steps are needed for daily operation.
Production Process Of Egg Carton Making Machine
This egg carton making machine has standardized and complete production steps. Each link connects closely and runs smoothly, detailed process as below：
- Raw Material Preparation Collect all kinds of waste paper as raw material. Common materials include cartons, newspapers and waste books. Sort out impurities in advance to ensure pulp quality.
- Hydrapulping Processing Put waste paper and water into the pulping tank. Stir and beat materials into fine paper pulp. No paper scraps remain in the pulp mixture.
- Pulp Mixing And Filtration Add appropriate additives into pulp as needed. Fully stir to make pulp texture even. Filter pulp to remove tiny impurities and residues.
- Vacuum Molding Forming Pump qualified pulp to the forming host. Vacuum adsorbs pulp on aluminum molds. Excess water drains away instantly. Wet egg trays take shape steadily.
- Drying And Shaping Transport wet trays to drying area orderly. Choose drying mode based on production scale. Gradually dehydrate to fix tray shape. Finished trays gain enough hardness.
- Stacking And Packaging Automatically stack dry egg trays. Arrange trays in neat piles. Complete simple packaging for storage. Directly deliver to market for sale.
Advantages Of YG Egg Tray Equipment
- Complete Model Coverage YG provides 1500 to 7000 pieces per hour models. It covers small startup to large industrial demands. Buyers can pick suitable units freely. YG also accepts custom high-output designs.
- Energy And Water Saving Design YG equips recycled water circulation systems. It cuts daily water waste greatly. Optimized motor design lowers power consumption. Long term production costs stay low for users.
- Strong And Durable Structure The machine frame uses thick steel plates. Core parts adopt famous brand accessories. Daily operation keeps stable with low failure rates. Service life can reach many years.
- Multi Functional Use Beyond standard egg trays, the machine makes egg cartons, fruit trays and wine holders. Changing aluminum molds can create new products easily. It adds more profit space for users.
- Simple Operation And Maintenance The control panel uses intuitive buttons. Workers can master operation quickly. Modular structure makes part replacement easy. It saves maintenance time and cost.
- Full Service Support YG provides site layout suggestions. It offers installation and operation training. Online technical support is available all year round. Spare parts supply is fast and convenient.
Egg Tray Making Machine For Sale FAQ
It can make many pulp packaging products. The machine supports egg cartons, fruit trays, shoe supports and wine trays. Custom molds can create special shaped trays as needed.
Four drying options are available. You can choose natural sun, drying oven, civil tunnel and multi-layer drying line. Low output fits sun drying, high output matches automatic lines.
The operation is simple to learn. The control interface is straightforward. YG provides free operation training. New workers can work independently in a short time.
The operation is simple to learn. The control interface is straightforward. YG provides free operation training. New workers can work independently in a short time.
YG Egg Tray Making Machine For Sale
All standard egg tray making machine for sale are in stock at YG. We support fast delivery for regular models. Custom configuration and mold design are also acceptable. YG has served clients across many countries. We deliver reliable machinery and thoughtful after sales service. If you have purchase plans, you can contact YG for a free quote and professional project advice at any time.
