Integrated Rock Drill and Splitter is a professional all-in-one rock breaking device. It integrates drilling and splitting functions into one single unit. Traditional rock breaking often relies on separate machines and blasting. These old methods bring high cost, noise and hidden safety risks. For this reason, YG develops Rock Drill and Splitter to optimize construction workflow.
This excavator drill and splitting machine can mount directly on standard heavy excavators. It matches excavators with weight above 25 tons for easy installation. Workers can finish drilling and splitting work without replacing multiple devices. Meanwhile, Integrated Drilling and Splitting Machine adopts full hydraulic driving design. It delivers stable power with low vibration and low working noise. It can operate normally in urban areas and environmentally protected zones.
Using this integrated machine also brings obvious economic benefits. It saves extra budget for purchasing independent drilling and splitting equipment. It cuts down labor input and shortens the whole project cycle. More global engineering buyers choose YG products for stable quality and reliable field performance.
Integrated Rock Drill And Splitter Main Technical Parameters
| Rock Drilling Machine | |||
| Power | Drilling hole diameter | Drilling depth | Drilling speed |
| 24kw | Middle 120mm | 1600mm | 1m/min |
| Splitting Machine | |||
| Splitting depth | Splitting force | Rotation angle | – |
| 1000MM | 8000T | 120° | – |
| Push Beam | |||
| Rock drilling maximum propulsion | Splitting maximum pullout force | ||
| 25KN | 70KN | ||
| Excavator requirements:>20T | |||
The standard equipment can reach stable drilling and splitting efficiency in most rock conditions. A complete round of drilling and splitting can finish within several minutes. Dense hard rock like granite can achieve long splitting length under proper site conditions. The machine maintains steady output capacity to meet daily engineering construction needs.
Application Fields Of Excavator Drill And Splitting Machine
- Quarry and Stone Mining :This machine suits natural stone quarrying and hard rock mining work. It replaces dangerous blasting with static rock splitting. It keeps rock integrity and improves raw stone utilization rate. It adapts to granite, limestone and other common hard rock types.
- Infrastructure Road and Tunnel Engineering: It undertakes hard rock breaking for road foundation and tunnel excavation. It can enter narrow construction spaces that large equipment cannot reach. It supports smooth progress of road expansion and mountain tunnel projects.
- Building Foundation and Pile Demolition: It breaks concrete pile heads and hard rock building foundations efficiently. It avoids strong impact from traditional breakers to surrounding buildings. It features small vibration and ensures safe and precise dismantling work.
- Urban Municipal Renovation Projects: Most urban regions ban blasting and high-noise construction operations. Integrated Drilling and Splitting Machine runs quietly with low vibration. It can work near residential areas, commercial streets and crowded municipal sites. It fully complies with urban environmental and construction regulations.
- Water Conservancy and Mountain Land Leveling :It handles hillside rock splitting, river base rock removal and land reshaping. It adapts to complex wild terrain and flexible moving conditions. It helps complete large-scale mountain renovation and water conservancy supporting projects.
YG Integrated Rock Drill And Splitter Core Advantages
1.Integrated One-piece Design Simplifies Construction Process
YG integrates drilling and splitting functions into one single device. Buyers do not need to purchase two sets of separate mechanical equipment. The whole on-site operation flow becomes simpler and more orderly. It also saves extra space for equipment placement and transfer.
2.Powerful Splitting Force Adapts To All Kinds Of Hard Rock
The machine is equipped with up to 8000T maximum splitting force. This unit handles most hard rocks such as dense granite and basalt. Long splitting spans are achievable in proper working conditions. The machine fully fits the demands of medium and large rock breaking projects.
3.Wide Excavator Compatibility With Quick Installation
YG equipment perfectly matches all excavators over 25 tons. It connects directly with the original hydraulic system of the excavator. It needs no large-scale mechanical modification before use. Ordinary operators can master basic operation skills in a short time.
4.Wireless Remote Control Ensures On-site Operation Safety
The machine is fitted with professional intelligent remote control system. It supports 120 degree rotating angle for multi-angle construction. Operators can stay away from dangerous rock splitting areas. It greatly reduces personal safety risks on rugged construction sites.
5.Premium Matching Configuration Extends Service Life
YG equips automatic oil injector and high-efficiency dust vacuum cleaner. Eight filter elements effectively block rock dust from entering internal parts. It reduces daily wear and lowers long-term maintenance costs. All key parts adopt high-strength materials for stable long-term operation.
6.High Working Efficiency Shortens Project Cycle
The whole drilling and splitting process finishes in a short time per hole. It delivers stable hourly rock processing capacity for continuous construction. Compared with traditional manual and mechanical breaking methods, it saves plenty of working time. It helps engineering contractors complete project tasks ahead of schedule.
FAQ About Integrated Rock Drill And Splitter
The machine is suitable for excavators above 25 tons. Conventional 25 ton and above heavy excavators can install and use it directly without modification.
It provides maximum 8000T splitting force. The power is enough to split most hard rocks and complete large-scale static breaking tasks.
A complete working cycle takes several minutes under normal rock conditions. The specific time will slightly change according to rock hardness and site environment.
Yes, it is fully applicable to urban non-blasting construction. It runs with low noise and tiny vibration and will not disturb nearby residents and buildings.
Yes, it has excellent performance on granite breaking. It can form long splitting length when the construction space and rock condition are proper.
Buy Integrated Drilling And Splitting Machine From YG
YG is a professional rock breaking machinery manufacturer with rich export experience. YG has complete production workshops and strict quality inspection standards. Every Integrated Drilling and Splitting Machine gets tested strictly before delivery.
YG can provide targeted machine selection suggestions according to your project demands. Our team offers clear parameter introduction and real construction site case references. You can get matched solutions based on local rock type and construction space.
The purchasing process of YG keeps simple and transparent. You only need to send your project demands to get a fast formal quotation. After order confirmation, YG arranges production and reliable global logistics arrangement. We supply English operation manuals and online remote installation guidance.
YG also provides long-term cooperative after-sales service. We keep sufficient spare parts in stock for fast global delivery. Our professional team offers online response all day to solve your operation and maintenance problems.
If you are searching for reliable and high-efficiency Integrated Rock Drill and Splitter, feel free to contact YG at any time. You can get a free customized quote and professional engineering solution right now.
