Concrete Floor Bead Blaster is essential industrial equipment for floor surface cleaning and roughening.It is also widely known as bead blaster floor machine in global engineering markets. This professional equipment uses mechanical force to shoot steel shots at high speed toward target surfaces. It can remove floating slurry, rust, old coatings and surface impurities efficiently.
Besides, the unit can adjust working depth by changing traveling speed. Slower moving speed brings deeper blasting effect, and faster speed keeps shallow grinding results. The machine matches a supporting dust collector to recycle steel shots automatically. It creates a dust-free working environment and cuts material waste greatly. YG provides multiple models of shot blaster for sale to meet different project width and efficiency needs.
Technical Parameters Of Concrete Floor Bead Blaster
YG launches three mainstream models with complete and stable parameters. All data comes from actual machine test and long-term construction feedback.
| Model | YG-270(Single) | YG550/600(Double) | YG-850(Double) | |
| Shot Blasting Wheel Diameter | 200mm | |||
| Working width | 270 mm | 550/600 mm | 800 mm | |
| Walking speed | 0.5~20 m/min | 0.5~33 m/min | ||
| Concrete surface cleaning efficiency | ≥180 m2/h | ≥400 m2/h | ≥600 m2/h | |
| Steel plate surface cleaning efficiency | 15-25 m2/h | 75-100 m2/h | 100-160 m2/h | |
| Dust connection pipe diameter | 120 mm | 150 mm | ||
| Suggest the diameter of steel balls | 1.2-1.5 mm | 1.5-1.8 mm | ||
| Steel pill consumption | 10 g/m2 | |||
| Supporting dust collector | Seven-core automatic backflush vacuum cleaner | Eight-core automatic backflush vacuum cleaner | ||
| Shot wheel motor | Power consumption | 11 kW | 11*2 kW | 15*2 kW |
| Input Current | ≤ 15 A | ≤ 22*2 A | ≤ 28*2 A | |
| Walking motor | Power consumption | 0.5 kW | 1.5 kW | |
| Input Current | 1 A | 3 A | ||
| Size (mm) | 1000*300*1100 | 1950*720/775*1400 | 1950*1020*1550 | |
| Weight | 150 kg | 570 kg | 700kg | |
| Power connection requirements | 400V, 50Hz, 100A, CEE socket | |||
Main Application Fields Of Concrete Floor Bead Blaster
The machine fits various construction and industrial scenarios. It shows stable performance in different ground and material conditions.
- Road and Bridge Engineering It cleans concrete road floating slurry and roughens bridge deck for waterproof construction. The machine also removes old traffic lines on municipal roads. It can handle airport runway glue removal and anti-slip surface treatment as well.
- Steel Structure Anti-Corrosion It can polish steel plates to reach Sa2.5 to Sa3 rust removal standard. Moreover, it works for nuclear power building decontamination and overpass painting pretreatment. It is also ideal for railway bridge surface cleaning and anti-corrosion projects.
- Commercial Flooring Renovation The bead blaster floor machine deals with peeling floors of underground garages. It roughens concrete base for epoxy floor laying. It also works on diamond sand cured ground with proper hardness for better adhesion.
- Other Industrial Scenarios It is suitable for asphalt surface roughness improvement and old factory floor renovation. It adapts to most outdoor and indoor engineering construction demands all year round.
YG Machinery Product Advantages
YG insists on using high-grade accessories and mature production technology for all blasting machine models. We focus on practical performance and long service life for global buyers.
- Robust integrated body structure. YG adopts thickened wear resistant steel for overall frame and protective parts. The whole machine resists strong impact and daily site abrasion. It keeps stable shape and performance after long time heavy duty work.
- Long service life for wearing parts. Standard daily use allows blasting wheels and directional sleeves to last around 20,000 square meters. Side and top guard plates can serve up to 50,000 square meters. It lowers regular replacement costs for users.
- Flexible adjustable working performance. Users control travel speed via frequency conversion system. They can easily adjust blasting depth to fit diverse construction needs. No extra tools are needed for on-site adjustment.
- Standard dust-free and eco-friendly structure. Every unit comes with an automatic back-blow dust collector. Steel shots get fully recycled while dust stays sealed inside. It meets global environmental construction standards perfectly.
- Strong adaptability for complex working sites. The machine accepts a maximum ground height difference of 1.5cm. Its working slope limit is under 25 degrees. It runs stably in temperatures ranging from -20℃ to 60℃.
- Complete factory direct sales configuration. YG full set includes dust collector, sand collecting cart, pipelines and spare blasting wheel. The brand also provides full spare parts supply with transparent prices for easy after-sales maintenance.
Frequently Asked Questions About Floor Shot Blaster
It works best on ground with unevenness below 10mm. The surface should stay dry with no standing water and slope under 25 degrees. Too much unevenness will cause uneven blasting and extra machine wear.
It can reach Sa2.5 to Sa3 standard for steel plate cleaning. Running speed directly affects the final grade. Slower travel speed creates a cleaner effect for heavy rust and oxide layers.
Concrete floors consume about 10g steel shot per square meter. Steel plate rust removal needs 50g to 80g per square meter. Actual usage changes with ground hardness and rust severity.
Improper installation of the directional sleeve is the main cause. Align the opening edge of the directional sleeve with the fixed screw. This simple adjustment can balance blasting coverage on both sides.
It is suitable for hard diamond sand cured ground for roughening tasks. It cannot be used on pure low-hardness diamond sand floor. Strong shot impact will damage the fragile surface structure.
Grab Premium Shot Blaster For Sale From YG With Best Factory Price
If you plan to buy reliable shot blaster for sale, YG is your ideal partner. We offer free product catalog, detailed parameter list and customized construction solutions. You can choose YG-270, YG-550 or YG-850 according to your project width and efficiency demand.
YG supports global logistics delivery and customized voltage service. Our professional team provides online technical guidance and long-term spare parts supply. Send your inquiry now to get the latest factory wholesale price and one-stop professional service support.
