Mini Excavator Quick Hitch is designed to help operators change attachments faster and work more efficiently. In modern construction sites, time is important, so reducing downtime becomes a key factor. This system allows a quick switch between different tools without manual pin removal. As a result, the Mini Excavator Quick Hitch improves working speed and reduces labor effort. At the same time, it supports safer and more stable attachment locking during operation.
The Mini Excavator Quick Hitch is widely used in excavation, demolition, recycling, and foundation work. It connects the excavator and attachments in a fast and secure way. With a strong locking system, operators can switch tools in a short time. Therefore, productivity increases while machine idle time decreases.
Mini Excavator Quick Coupler Technical Parameter
| Item/Model | Unit | YGMINI | YG45 | YG50/55 | YG60/65 | YG70/80 | YG90 | YG100/110 |
| Suitable Excavator | ton | 1.5-4 | 4-7 | 5-8 | 9-19 | 17-23 | 23-30 | 33-45 |
| Weight | kg | 25 | 50-60 | 80 | 120-130 | 280-290 | 420-430 | 450-580 |
| Length | mm | 388 | 534-545 | 600 | 765 | 924-944 | 983-1050 | 1006-1473 |
| Height | mm | 246 | 307 | 310 | 388 | 492 | 574 | 558-610 |
| Width | mm | 175 | 258-263 | 270-280 | 353-436 | 449-483 | 543-568 | 606-663 |
| Pin-to-Pin Center Distance | mm | 80-150 | 230-270 | 290-360 | 380-420 | 460-480 | 473-540 | 550-620 |
| Forearm Open Width | mm | 80-140 | 155-170 | 180-200 | 232-315 | 306-340 | 375-411 | 416-469 |
| Retractable Distance of Oil Cylinder | mm | 170-206 | 205-275 | 340-450 | 340-486 | 256-390 | 413-590 | 520-590 |
| Top-to-Bottom Pin Distance | mm | 159 | 195 | 195 | 220 | 275 | 300 | 360 |
| Pin Diameter | mm | 25-40 | 45-50 | 50-55 | 60-70 | 70-80 | 80-90 | 90-120 |
| Working Pressure | bar | 32-40 | 32-40 | 32-40 | 32-40 | 32-40 | 32-40 | 32-40 |
| Working Flow | Ipm | 10-20 | 10-20 | 10-20 | 10-20 | 10-20 | 10-20 | 10-20 |
This Mini Excavator Quick Coupler parameter table helps users select the right model based on excavator size and working conditions. Each model is designed with stable hydraulic control and reliable locking strength. Therefore, operators can match different machines with confidence.
Quick Hitch Excavator Structure and Working Principle
Quick Hitch Excavator uses a compact structure that combines hydraulic power and mechanical locking. It mainly includes a frame body, hydraulic cylinder, locking hook, and safety valve system. These parts work together to ensure stable connection between the excavator and attachments.
When the operator activates the system, the hydraulic cylinder moves the locking hook. Then the attachment is released smoothly. After positioning a new tool, the system locks it again within seconds. In this process, the Mini Excavator Quick Hitch ensures stable connection and reduces human error.
In addition, the safety locking system prevents accidental detachment during work. This design improves operator confidence and supports long-term use in harsh environments.
Mini Excavator Coupler Multi Scenario Construction Solutions
Mini Excavator Coupler plays an important role in different construction environments. With quick switching ability, one excavator can handle multiple tasks without delay.
In demolition projects, tools like hydraulic shears and drum cutter machines help remove concrete structures efficiently. In foundation work, pile drivers and pile breakers improve construction speed and accuracy.
For recycling tasks, orange peel grapples and magnet attachments make material handling easier and cleaner. Meanwhile, in mining and rock work, rock splitters and integrated rock drill systems support hard material breaking.
Because of the Mini Excavator Quick Hitch, operators can switch between these tools quickly. As a result, one machine can complete multiple jobs in a single day. This improves overall project efficiency and reduces equipment costs.
How to Choose a Suitable Quick Hitch Excavator System？
Choosing the right Quick Hitch Excavator system depends on several key factors. First, users should match the coupler with excavator tonnage. This ensures stable performance during operation.
Second, pin size and center distance must be checked carefully. Incorrect matching may reduce efficiency or affect safety. In addition, users should consider working conditions such as demolition, mining, or construction sites.
Hydraulic systems are better for frequent switching tasks. Mechanical systems may suit lighter workloads. Therefore, selecting the right type depends on real working needs.
Finally, durability also matters. High-strength steel and stable hydraulic components help extend service life and reduce maintenance needs. Proper selection ensures better performance in long-term use.
Purchase YG Mini Excavator Quick Hitch Reliable Supply Solution
YG Machinery provides Mini Excavator Quick Hitch solutions designed for different excavator models and complex working conditions. The system is built with stable quality control and practical engineering design. Therefore, operators can achieve smoother attachment switching and more efficient job performance.
At the same time, YG offers a wide range of excavator attachments that can work together with the Mini Excavator Quick Hitch. These include Excavator Orange Peel Grapple, Drum Cutter Machine, Hydraulic Shears For Excavator, Excavator Pile Driver, Excavator Magnet Attachment, Hydraulic Pile Breaker, Rock Splitter For Excavator, and Integrated Rock Drill And Splitter. With these tools, one excavator can easily handle demolition, recycling, foundation work, and rock breaking tasks without frequent equipment replacement.
Because of this combination, the Mini Excavator Quick Hitch becomes a key connection system that improves overall construction flexibility. Operators can switch between different attachments within a short time, which helps reduce downtime and improve project continuity. In addition, each attachment can be matched based on specific job requirements, making the system more practical for real construction environments.
YG also supports customized solutions based on excavator tonnage and working needs. Customers can share machine specifications and application scenarios to receive suitable recommendations. This ensures better matching between the coupler and attachments, especially in multi-task construction projects.
Finally, global shipping and technical support are available. If you are planning to upgrade your equipment system with a Mini Excavator Quick Hitch, YG Machinery can help you build a complete attachment solution that improves efficiency and expands machine capability.
