YG Machinery produces high-performance wire saw machines. We design them as a reliable quarry wire saw and rock wire saw. Our stone wire saw for sale provides accurate cuts for many materials. These machines help you finish projects faster and with less waste. In addition, we offer complete packages with power units and diamond wire. Our team supports you from selection to operation.Our wire saw machine handles quarry and rock cutting tasks. You can choose from hydraulic, electric, and tracked models. This stone wire saw for sale delivers dependable results on any jobsite.
Wire Saw Machine Parameters
| Wire Saw Wheel Parameters | Hydraulic Pump Parameters | ||
| Wire Drive Mode | hydraulic | Motor Power | 22/25kw |
| Motor Type | HM-80, 2 Cylinders | Voltage | 220V/380V, 50Hz |
| Minimum Input Power | 25HP/33HP | Hydraulic Pump Type | Gear Pump |
| Output Shaft Speed | 350/940/1300r/min | Main Drive Motor | 40-100L/min |
| Maximum Wire Length | 20m | Working Pressure | 15-20Mpa |
| Feeding Method | Fully hydraulic | Oil Tank Capacity | 17L |
| Wire Saw Wheel Weight | 64kg | Weight | 160kg |
| Motor Weight | 14kg | Size | 700*700*1200mm |
| Size | 1700*700*800mm |
What Is a Wire Saw Machine?
This equipment uses a diamond wire to cut stone and concrete. It loops the wire through the material and drives it at high speed. This method replaces traditional blasting and circular saws. It creates straight, smooth cuts with little vibration. You can use it in quarries, on construction sites, and underwater. The technology saves material and reduces noise compared to older cutting methods.
Main Components and Working Principle of a Quarry Wire Saw
A quarry wire saw system includes several key parts. First, the drive wheel with an integrated hydraulic motor provides power. Second, the diamond wire features spring or plastic-injected beads. Third, a hydraulic power pack supplies high-pressure oil. Fourth, guide pulleys and a feeding system control the wire path. Finally, a control unit lets you adjust speed and feed pressure.
Here is how the components work together. The hydraulic power pack sends oil to the motor. The motor rotates the drive wheel. This action pulls the diamond wire through the stone. A fully hydraulic feeding system advances the cutting head steadily. Meanwhile, cool water flows continuously over the wire. The water removes dust and prevents overheating. As a result, you get a clean, accurate cut with minimal wear on the wire.
Application Fields of Rock Wire Saw
- Quarrying. You can extract marble, granite, and limestone blocks efficiently with a rock wire saw. It produces uniform blocks and reduces waste.
- Rock trenching. The rock wire saw cuts trenches, channels, and large boulders with high precision. It handles uneven rock faces easily.
- Concrete demolition. You can remove reinforced walls, pillars, and bridge decks without damaging nearby structures. The low-vibration cut protects the remaining concrete.
- Underwater operations. Special sealed components allow submerged cutting for dam repair and marine construction.
- Block dressing. Trim and square dimensional stone blocks right in the processing yard. This step speeds up your production line.
YG Wire Saw Machine Advantages
Our wire saw machines bring many benefits to your operation. They combine strong power, smart design, and easy maintenance.
- Strong Cutting Capability. The high-torque hydraulic motor handles hard granite and heavily reinforced concrete with ease. It maintains steady power even under heavy loads. The drive wheel transfers maximum torque to the diamond wire.
- Flexible Operation. The wire saw drive wheel weighs only 64 kg. You can install it quickly in tight spaces or on high walls. Moreover, the variable speed settings give you full control over the cutting process.
- High Efficiency. Three output speeds up to 1300 rpm and a 20 m wire length boost your productivity. You finish jobs faster than with older methods. In addition, the fully hydraulic feeding saves setup time.
- Diverse Configurations and Strong Adaptability. Mount the unit on rails, columns, or a tracked base. This makes horizontal, vertical, and angled cuts possible. The system adjusts to different wire lengths and pulley arrangements easily. Therefore, one machine can handle many job site requirements.
- Wide Consumable Selection. We supply spring, plastic-injected, and rubberized diamond wires. Bead sizes range from 7.3 mm to 11.5 mm. Choose the right bond and grit for your specific stone or concrete. Our team will help you match the consumables to your rock type.
- Multiple Power Options. We offer hydraulic wire saws, electric wire saws, and tracked wire saws. Hydraulic models suit outdoor quarries perfectly. Electric wire saws fit indoor or emission-controlled areas. Tracked wire saws provide excellent mobility on rough terrain. This variety ensures you always find the right drive type.
FAQ About Stone Wire Saw For Sale
It cuts marble, granite, sandstone, limestone, and reinforced concrete. The diamond wire type determines the best cutting performance on each material. For example, a softer bond works well on hard granite, while a harder bond suits soft limestone.
With the standard 20 m wire and proper guide pulley positioning, you can reach over 10 meters deep. The actual depth depends on the material and how you route the wire. Our engineers can help you plan the setup for maximum cut depth.
Yes, you can. Our hydraulic wire saw works underwater with sealed components. We supply special diamond wires for submerged cutting. Just ensure the power pack stays above water and the wire receives adequate cooling flow.
We recommend spring wire for soft stone, plastic-injected for medium-hard rock, and rubberized wire for concrete. Bead size and bond hardness also matter. Contact us with your material details, and we will suggest the ideal configuration.
Most standard wire saw packages ship within 7 to 15 days. Custom configurations may need extra production time. Reach out to check current stock and receive a precise delivery schedule.
YG Wire Saw Machine In Stock and Other Machinery
We keep several wire saw configurations in stock. Complete packages with drive units, power packs, and diamond wire are ready for shipment. You can find the right stone wire saw for sale and start your project quickly. Besides wire saws, YG Machinery manufactures a full line of reliable construction equipment. Our range includes Industrial Shot Blasting Machine, Skid Steer Track Loader, Small Wheel Loader, Compact Backhoe Loader, Hydro Seed Machine, Tracked Mini Crane, Hydraulic Stone Splitter, Concrete Mixer And Pumping Machine, Automatic Brick Making Machine, and GRC Machine. Contact YG Machinery today for a tailored quotation. Our engineers provide lifetime technical support and help you choose the best equipment for your needs.
